PPDA-20/30/40kW Portable DC EV Charging Station
DC Charger
- Portable EV Charging Station
- Mobile DC charging vehicle
- OCPP1.6J+APP+DLB
- CCS1/CCS2/GBT
- 4G/WIFI/RFID
- 7 inch touch screen
- fast charge
- IP55 IK10
- E-stop button
- European Standard (CE)
▏ Description
The PPDA-20/30/40kW Portable EV Charging Station is a compact and mobile charging solution for electric vehicles (EVs), offering high-power outputs of 20kW, 30kW, or 40kW. It is designed for flexibility in temporary setups, events, and emergency situations where rapid charging is needed. The station features user-friendly controls, compatibility with various EV models, and robust safety measures including overcurrent protection and temperature monitoring.
▏ Specification
Feature
Charging mode:PPDA
Charging connector:lEC 62196 Type 2 cable
DC power output:20kw/30kw/40kw
HMI:Logo LED, Status LED
Load management:Via App
General Design
Operating temperature ：-30 to 55°C with derating mechanisme
Operating altitude ：2500m
Environmental rating ：Indoor and outdoor, lP55,lK10
Dimension：600*270*520mm
Electrical Design Power supply:
230/400VAC+20%,50/60HzTN/TT/T Protection:UVP, OVP, OCP, Relay Stuck, Over Temperature
Energy metering :±2% Accuracy
Communication
Interface:WiFi/4G/Ethernet
User authentication:RFID, App, Plug and Charge Backend protoco:OCPP 1.6 JSON upgrade:OTA via App, OCPP
▏ Technical Parameters
Maximum Power
20kw/42A 400VAC ; 30kw/60A 400VAC；40kW/80A 400VAC
Connector
CCS1/CCS2/GBT/ChadeMO
Dimension (H*W*D)
540*210*520mm
Display
LCD:4.3-inch touch screen
Installation
Portable
Certification
CE
Ingress Protection
IP54,IK10
Dynamic Load Blancing
Solar Charging
▏ Product Showcase
Featuring card payment, APP control, OCPP 1.6 compatibility, WiFi/4G/Ethernet connectivity, and 20/30/40kw outputs, our charging station offers a seamless EV charging experience
Safety Instructions for Charging Stations
Equipped with leakage, overvoltage, overtemperature, lightning, and waterproof protections, our charging stations ensure safe, reliable charging for your EV. Use with confidence.
▏ FAQ: Addressing Common Queries
1.Is there a portable charger available for EV cars?
Yes, there are portable chargers available for electric vehicles (EVs). These chargers are designed to be compact and easy to transport, allowing EV owners to charge their vehicles on the go.
2.Can I charge my EV with a portable power station?
Yes, you can charge your electric vehicle (EV) with a portable power station, but there are some important considerations to keep in mind.
3.How do portable ev charging station work?
Portable EV chargers plug into a power source, such as a standard household outlet or a portable power station, and connect to your EV using the appropriate charging connector. They convert the power from the outlet to a suitable form for charging the vehicle’s battery.
4.Can a portable generator charge an EV?
Yes, a portable generator can charge an electric vehicle (EV), but there are important considerations to ensure safety and compatibility.
5.What type of portable generator is suitable for charging an EV?
A generator with a stable output and sufficient power rating (typically at least 3 kW for Level 1 and 7 kW or higher for Level 2 charging) is required. Inverter generators are preferred because they provide a more stable electrical output, which is safer for your EV’s electronics.
